Test topic 2 - will be removed soon.

In CFD we generally have a problem when we encounter something that is supposed to move on its "free will". One of these problems is an unknown rotation speed of a turbomachinery rotor. Common practice is that the user prescribes flow boundary conditions for one specific case or does a full spectrum of operational conditions including rotation speed. But what if he knows an input aerodynamic or shaft torque and wants to obtain a stable rotation speed (with no acceleration)?

One way is to use the TOPT algorithm where you look for a minimum of optimization function prescribed as (target_torque - calculated_torque)^2.

First I calculated a torque for 187 RPM. Then I set this torque to our optimization function and ran TOPT with RPMs as a parameter.

After several runs, the RPMs started to converge around the value of 187 as they should. The DIRECT algorithm was still trying other options, but got to the minimum of our function relatively quickly.

Test topic - will be removed

Testing New Topic For Mail

Axial Turbine Stage - test topic. Axial Turbine Stage CFD. It is hard not to be emotional when seeing an axial turbine stage CFD. The axial turbine stage was our first big CFD project made here at CFDSUPPORT. In a way, it had preset our destiny - turbomachinery simulations. Here is a little example of how now, ten years later, TCAE runs the whole complex process in one command (or click). By TCFD: https://www.cfdsupport.com/axial-turbine-cfd-simulation.html

Test topic for email notification to support@cfdsupport.com, Comment Yes if you receive the email.

test

test

Hello,

I would like to present my current project for further experiments with TCAE and TOPT.

It is a parametric axial fan created in the OpenVSP free parametric CAD primarily used for aviation purposes. It allows controlling the geometry with pre-programmed parameters and their further linking. It can also be controlled by external scripts. All these functions are perfect premises for geometry optimization with our TOPT module.

This model is designed for catalogue-like making of fans for defined conditions. You create a spectrum of axial fan variation and then choose which one suits the best (with consideration on parameters like pressure drop or aerodynamic torque and then fan efficiency calculated from them).

Simplified model will be used in the upcoming TCAE tutorial, where only a few basic blade parameters will be modified. Its main purpose there will be demonstration of the TOPT capabilities and their potential use in industrial design.

Hello everyone,

I have just installed the new version 23.03v1.

I wonder in which cases it is necessary / recommanded / relevant to enable "Use external geometries / meshes (file will not be imported into the project)" in TMESH in this new version 23.03v1 ? I have noticed that in TCAE/tutorials repertory, it is enable only when TOPT is used.

In my case I have got an already meshed geometries from FLUENT but I have seen that it is possible to both enable/disable this feature. But I have encountered some issues when it is disabled. More specificaly, sometimes, when I restore the project, one interface (inlet/outletInterface) disappear.

What do you recommend?

Dear Team,

I am trying to run a simulation of the FDA Benchmark Blood Pump case with TCAE. I am using my meshes that I have generated by myself (not via TMESH).

The project case setup seems to be fine, and I get the message "Project Setup OK" upon checking. However, when I start the TCFD run, I get the following error message after a while -

"--> FOAM FATAL IO ERROR:

Cannot open include file "C:/Users/KaranBaliga/Desktop/TCAE/GridPro Blood Pump/Fluent_Grids_GridPro/GridPro_Blood_Pump/simulationRun1/TCFD/transient/1_1/system/hi.fun" while reading dictionary "C:/Users/KaranBaliga/Desktop/TCAE/GridPro Blood Pump/Fluent_Grids_GridPro/GridPro_Blood_Pump/simulationRun1/TCFD/transient/1_1/system/controlDict/functions"

file: C:/Users/KaranBaliga/Desktop/TCAE/GridPro Blood Pump/Fluent_Grids_GridPro/GridPro_Blood_Pump/simulationRun1/TCFD/transient/1_1/system/controlDict at line 78.

From function static bool Foam::functionEntries::includeEntry::execute(Foam::dictionary&, Foam::Istream&)

in file db/dictionary/functionEntries/includeEntry/includeEntry.C at line 169.

FOAM exiting"

I do not know why this error occurs. Can you please help me out?

If required I can attach the case files as well.

Thanks and Regards,

Karan H Baliga,

GridPro.

Dear Team,

I am trying to run a simulation of the FDA Benchmark Blood Pump case with TCAE. I am using my meshes that I have generated by myself (not via TMESH).

The project case setup seems to be fine, and I get the message "Project Setup OK" upon checking. However, when I start the TCFD run, I get the following error message after a while -

"--> FOAM FATAL IO ERROR:

Cannot open include file "C:/Users/KaranBaliga/Desktop/TCAE/GridPro Blood Pump/Fluent_Grids_GridPro/GridPro_Blood_Pump/simulationRun1/TCFD/transient/1_1/system/hi.fun" while reading dictionary "C:/Users/KaranBaliga/Desktop/TCAE/GridPro Blood Pump/Fluent_Grids_GridPro/GridPro_Blood_Pump/simulationRun1/TCFD/transient/1_1/system/controlDict/functions"

file: C:/Users/KaranBaliga/Desktop/TCAE/GridPro Blood Pump/Fluent_Grids_GridPro/GridPro_Blood_Pump/simulationRun1/TCFD/transient/1_1/system/controlDict at line 78.

From function static bool Foam::functionEntries::includeEntry::execute(Foam::dictionary&, Foam::Istream&)

in file db/dictionary/functionEntries/includeEntry/includeEntry.C at line 169.

FOAM exiting"

I do not know why this error occurs. Can you please help me out?

If required I can attach the case files as well.

Thanks and Regards,

Karan H Baliga,

GridPro.

CFDSUPPORT decided to publicly and freely share their OpenFOAM training materials.

The OpenFOAM training materials provided by CFDSUPPORT are an invaluable resource for anyone interested in learning OpenFOAM. With nearly 500 pages of comprehensive training material, the guide offers a step-by-step learning process that is tailored to suit the needs of both beginners and advanced users.

The guide covers a wide range of topics, including the basic principles of fluid dynamics, meshing, case setup, solver selection, post-processing, and more. The material is presented in a clear and concise manner, making it easy to understand even for those with little or no prior knowledge of CFD or OpenFOAM.

The training materials are accompanied by numerous examples and exercises that help reinforce the concepts covered in the guide. This hands-on approach is particularly useful in helping users develop the skills necessary to work with OpenFOAM effectively.

Moreover, the guide is available for free, making it accessible to anyone who is interested in learning OpenFOAM, regardless of their financial resources. This is a testament to the commitment of CFDSUPPORT to promoting education and innovation in the field of CFD.

Overall, the OpenFOAM training materials provided by CFDSUPPORT are a great resource for anyone looking to learn OpenFOAM, and I would highly recommend them to anyone who is interested in pursuing a career in CFD.

The download link is below in the comment section.       Please register to access it.

Some topics are in error. Check the following topics:

Test Image Aspect ratio 230206 13:00

Open Source for CAE

Notice: the topics in error don't have tags, can this be the reason for the error?
